ZF Testman DPA06 Diagnostic Tool with Cables | ZF Transmission Diagnostic Tool
  • ZF-Testman Pro checks the functionality of all electronically controlled ZF products.
  • All transmission-specific data required for a fast and comprehensive diagnosis are retrievable by the ZF diagnosis system Testman.

DHL-EXPRESS-DELIVERY

trust-pilot-reviews

Day
Hour
Min
Sec
Price:
2,849.00€
3,000.00€
  • : In Stock! Estimated Delivery Time: 2-4 Days
  • Brand: BALTICDIAG
  • Model: DPA06

Available Options



ZF-Testman Pro checks the functionality of all electronically controlled ZF products. All transmission-specific data required for a fast and comprehensive diagnosis are retrievable by the ZF diagnosis system Testman.

With the assistance of the ZF-TESTMAN, you are best equipped for present and future challenges and will profit directly from the expertise of ZF, a leading worldwide company in driveline and chassis technology.

Please note, that this product comes without diagnostic software!

Diagnose:

  • Current errors;
  • Read error memory;
  • Delete error memory;
  • Read identification block;
  • Vehicle data sheet;



Test Inputs and Outputs:

  • System-check standstill;
  • System-check run;
  • Test unit (indication of all digital inputs and outputs);
  • Indication of all digital and analog values such as speeds, currents and voltages;



Repair support:

  • Tightening torques;
  • Setting data;
  • Special tools;
  • Test equipment;
  • Maintenance;
  • Repair work;
  • Pressures;
  • Circuit diagrams;
  • Electrical readouts;
  • PDF format;



Vehicle configuration:

  • Depending on product all vehicle specific data can be stored or shift programs selected and adjusted.







Supported commercial vehicle/special transmissions:

  • ASTRONIC (1, 2, mid, lite, lite test rig, 2 assembly inspection, 2 test rig)
  • ECOMAT (1, 2/4, HP 260 CAN-Converter)
  • INTRADER (EST32, EST42/48)
  • AVS
  • eTRONIC
  • WSK EST 41/61



Supported marine propulsion systems:

  • BW



Supported commercial vehicle steering systems:

  • ZF Servocom RAS-EC (RAS-EC ISO, RAS-EC KWP)
  • ZF Servocomtronic (Servotronic F)



Supported automobile car steering systems:

  • EHPS (BMW R50, OPEL EP2)
  • ZF Servolectric (BMW E85, APA E72, APA E90, VW PQ35/45 + Audi TT, VW PQ35-3)
  • ZF Active Steering (BMW E60 PL1, E70 PL4, E90 PL2)
  • ZF Servotronic (Servotronic F)



Supported off-road driveline technology and asle systems:

  • ERGOPOWER (WG110-WG311, 2-3 WG-94, EST 117/125 - 119/126)
  • T7000 (T7100 EST38, T7200 EST38, T7300 EST38, T7000 EST45/57/57A/ PVS LS EST57A)
  • ECCOM (John Deere, Claas)
  • T557 EST57A
  • HC 85










  • DPA06 Interface
  • 2 x Bluetooth sticks
  • Mini USB cable
  • USB cable
  • LAN cable
  • 15-pin male to female adapter
  • OBD2/5-pin cable - CAN (VEH)/K-line (optional pins)
  • 6-pin EST-37 cable - special version passau (only K-line)
  • 9-pin JPT (yellow) cable - CAN (ZF+VEH)/K-line
  • 9-pin MNL (white) cable - CAN (ZF)/J1708
  • 9-pin MNL (white) cable - CAN (ZF)/K-line
  • 9 to 6/3-pin cable - CAN (ZF)/K-line
