Mobile Diesel Generator 9.5kW | BD12500SE

-17 %

Mobile Diesel Generator 9.5kW | BD12500SE

Disclaimer: This product does not include free shipping. For delivery pricing and additional information, please contact us directly.

Price:

1,500.00€

1,814.05€

: In Stock! Estimated Delivery Time: 2-4 Days
Brand: BALTICDIAG
Model: BD16925

Qty

Buy now

Ask Question

Add to Wish List

Description

Disclaimer: This product does not include free shipping. For delivery pricing and additional information, please contact us directly.

Mobile Diesel Generator 9.5kW BD12500SE

Mobile diesel generator BD12500SE is a powerful, reliable and easy-to-use device that ensures stable power supply even in extreme conditions. With a power of 9.5 kW, this generator is perfect for both domestic and professional use. Its features make it an indispensable device on construction sites, temporary event venues or as a backup power source in the household. This diesel generator is an economical and functional solution that will guarantee reliable power supply when you need it most.

Features:

Electronic generator start system
Maintaining equal power when working in all phases. The generator has a function that allows the generator user to select the desired electrical voltage, 400 V or 230 V. Due to this feature, the generator can generate 100% of power when working in three phases and even 85-90% when working in one phase. When conventional diesel three-phase generators only produce 33% of the power per phase.
Digital generator information display
A heater is installed. In low temperatures and if there is a problem with starting the generator, press and hold the heating button for about 10 seconds. Thanks to this action, you will warm up the air in the air supply system, which will allow the generator to start much easier and smoother
Compatible with an external ATS device. This ATS device can be purchased additionally for 270.00 Eur including VAT
Quality generator wheels. The mobile diesel generator weighs approximately 150 – 350 kg, so these rubber generator wheels ensure smooth and high-quality transportation of the device

Frequently Asked Questions

Do you offer international shipping for your products? ❯: Yes, we offer fast and free international express shipping for all products available at Balticdiag.com. We deliver worldwide — including USA, Europe, North America, South America, Asia, Africa, and Australia — using trusted courier services like DHL, UPS, and FedEx. Every order is shipped with express delivery straight to your door, ensuring quick and secure arrival. Shipping fees are included in the product price, and we provide full tracking information for each shipment so you can follow your package from dispatch to delivery.
How can I pay for my order on Balticdiag.com? ❯: We accept a wide range of secure global and local payment methods, including:

Credit & Debit Cards: Visa, Mastercard, American Express, Discover, Diners Club, JCB, China UnionPay, Cartes Bancaires (France)

Digital Wallets: Apple Pay, Google Pay, PayPal, Alipay, Revolut Pay, MobilePay (Denmark & Finland), Link with Instant Bank Payments (USA)

Local Payment Methods: Bancontact (Belgium), BLIK & Przelewy24 (Poland), iDEAL (Netherlands), giropay (Germany), EPS (Austria), Klarna (buy now, pay later), SEPA Direct Debit (EU), Kakao Pay, Naver Pay, PAYCO (South Korea)

Bank Transfers: We also support traditional wire transfers.

Generated stand-by electrical power:	10 kW / 12.5 kVA
Generated prime electrical power:	9.5 kW / 11.9 kVA
Generated electrical voltage:	230 / 400 V
Frequency:	50 Hz
Number of phases:	three-phase with selection
AVR system:	integrated
AVR voltage regulation accuracy:	± 0.5%
DC output:	12 V / 8.3 A
Generator type:	synchronous
Generator starting system:	electronic
Noise level (~ 7 m):	70 – 73 dB
Cooling system:	air-cooled
Number of cylinders:	1 cylinder
Piston duty cycle:	4-stroke
Engine speed:	3000 rpm
Engine model:	1103F
Engine displacement:	734 cm3
Piston diameter and stroke:	103 x 88 mm
Fuel consumption at 100% load:	2.66 l/h
Fuel consumption at 75% load:	1.988 l/h
Fuel consumption at 50% load:	1.33 l/h
Fuel tank capacity:	30 l
Continuous working:	9.7 h
Oil capacity:	2.5 l
Fuel supply system:	direct injection
Operating temperature:	from - 15 °C to + 40 °C
Battery capacity:	36 Ah
Output power plugs:	integrated
Integrated circuit breakers:	1 fz - 50 A / 3 fz - 16 A
Protection class:	IP23
Package dimensions:	1115 x 650 x 930 mm
Weight:	228 kg

Generated stand-by electrical power:	10 kW / 12.5 kVA
Generated prime electrical power:	9.5 kW / 11.9 kVA
Generated electrical voltage:	230 / 400 V
Frequency:	50 Hz
Number of phases:	three-phase with selection
AVR system:	integrated
AVR voltage regulation accuracy:	± 0.5%
DC output:	12 V / 8.3 A
Generator type:	synchronous
Generator starting system:	electronic
Noise level (~ 7 m):	70 – 73 dB
Cooling system:	air-cooled
Number of cylinders:	1 cylinder
Piston duty cycle:	4-stroke
Engine speed:	3000 rpm
Engine model:	1103F
Engine displacement:	734 cm3
Piston diameter and stroke:	103 x 88 mm
Fuel consumption at 100% load:	2.66 l/h
Fuel consumption at 75% load:	1.988 l/h
Fuel consumption at 50% load:	1.33 l/h
Fuel tank capacity:	30 l
Continuous working:	9.7 h
Oil capacity:	2.5 l
Fuel supply system:	direct injection
Operating temperature:	from - 15 °C to + 40 °C
Battery capacity:	36 Ah
Output power plugs:	integrated
Integrated circuit breakers:	1 fz - 50 A / 3 fz - 16 A
Protection class:	IP23
Package dimensions:	1115 x 650 x 930 mm
Weight:	228 kg
