  • Test your vehicle in real life conditions through our intuitive and game changing App

 FREE EXPRESS WORLDWIDE DELIVERY

Price:
1,240.00€
  • Stock: In Stock
  • Model: DynoRoad

DynoRoad Car Test

Is a fast and easy road dynamometer for testing your vehicle's performance DynoRoad is an innovative mobile car dyno that measures power and torque in both electric and traditional vehicles via an app installed on your mobile device. This road dyno is so small and compact you can always have it with you, and it can be installed on your car in just two minutes.

So Easy, So Fast, So Accurate

Getting started with DynoRoad is as easy as mounting the car dyno on the vehicle’s wheel, pressing the ON / OFF switch and connecting it to your mobile device.

Fasten your seat belts and start your engine: after activating your car dyno with a Magicmotorsport account, you’ll need to enter your car details to perform  accurate measurements.

You can quickly and easily calibrate DynoRoad by maintaining 3000RPM for 5 seconds, while moving your vehicle at least 30 kmh in 4th gear. Additionally, you can change these settings to accommodate different vehicles by adjusting RPM level, gear choice and elapsed time to your desired values. Once the calibration is successful you're ready to roll!

Performing a Car Dyno Test is no Longer a Problem

With DynoRoad the measurements are highly accurate and repeatable by simply entering the correct vehicle weight and the tire dimensions. In addition, this car dyno has an integrated weather module that will allow you to measure ambient temperature and atmospheric pressure. DynoRoad allows you to consistently repeat results under similar conditions with a margin of error of less than 1%.




Smart Mobile Application

DynoRoad’s application software user interface is simple and intuitive, designed for anyone that knows how to use a mobile phone. The app walks you through the initial set-up of the car dyno and gives you clear and understandable options to accurately measure the horsepower and torque of your vehicle but you can also analyze and compare the results of these measurements.

  • Measure vehicle power in a real-life scenario
  • Customize your reports to your needs
  • Analyze your measurements
  • Compare your modification results

Robust Design

Light yet durable, DynoRoad is made in from a solid aluminum body designed to preserve its sturdy characteristics and assure device longevity.

Internally Charged

Completely portable, DynoRoad comes equipped with an internal battery that allows you to perform various test on the go and includes a USB-type C port for charging.

Long Lasting Battery

Take your time with your car tests. Our integrated battery can take up as many measurements you need with its extensive battery life - up to 10hrs of work.

High Accuracy

With it's built in sensors and complex algorithms, your results will be rock solid, especially now that you can test your car in a real-life scenarios - on the road.



What is a dynamometer?

A dynamometer, or dyno for short, is a device for the measurement force, moment of force (torque), or power. For example, the power produced by an engine, motor or other rotating prime mover can be calculated by simultaneously measuring torque and rotational speed (rpm).

How does a dyno test work?

Installing
First, Install DynoRoad on the vehicle wheel in the non-drive axle.

After mounting the dynamometric probe with the supplied connections, press the ON / OFF switch.

After pressing the ON/OFF button, the white STATUS LED flashes.

From this moment on it will be possible to connect the car dyno to the App and be guided in the power tests.

Fasten your seat belts and start your engine: after activating the device through the MAGICMOTORSPORT account, the configuration will be started.

In the first screen, configure the measurement by specifying the parameters: name and brand of the vehicle, size and mass,and tire size.

You can calibrate DynoRoad by maintaining 3000RPM for 5 seconds, while moving your vehicle at least 30 kmh in 4th gear. Additionally, you can change these settings to accommodate different vehicles by adjusting RPM level, gear choice and elapsed time to your desired values.

Measurement
The measurement involves two phases:

Phase 1. Acceleration

Phase 2. Automatic deceleration after idle. The second phase lasts about 10 seconds. The program automatically signals the end of the deceleration phase with an acoustic signal.

Press GO to start measuring. The message "you can move" is displayed. Vehicle power measurement is usually done in third or fourth gear in the available engine speed range.

To accurately calculate the torque and obtain the correct graph, it is advisable to move the vehicle in first and second gear at low speed, then after engaging the third or fourth gear, launch the measurement.

The application also allows you to enter a very precise acceleration time from 0 to 100 km / h, up to 200 km / h, and drive for a ¼ mile stretch during which engine performance can be measured and evaluated.

Regardless of the transmission type, the GO button and the accelerator pedal will be in the same position.

After reaching the required speed or measuring range, the vehicle can be stopped. When braking the power values ​​will be incorrect, but the acceleration results will be correct and will automatically appear on the screen when a certain speed is reached on a stretch of road.

How do I get Dynamometer?

DynoRoad is available on our online store, shippable all over the world.
