Name: Electric pallet stacker 1500 kg BD-ES15i | BALTICDIAG
Brand: BALTICDIAG
Price: 2470.25 EUR
Availability: InStock

Electric pallet stacker 1500 kg BD-ES15i | BALTICDIAG

Shipping Notice: Free delivery does not apply to this item. Delivery costs are calculated based on your location. Please contact us for a shipping quote before or after placing your order.

Price:

2,470.25€

: In Stock! Estimated Delivery Time: 2-4 Days
Brand: BALTICDIAG
Model: BD71502
Weight: 558.00kg
Dimensions: 1,735.00mm x 800.00mm x 2,240.00mm

Qty

Buy now

Ask Question

Add to Wish List

Description

Electric Pallet Stacker 1500 kg, BD-ES15i

Shipping Notice: Free delivery does not apply to this item. Delivery costs are calculated based on your location. Please contact us for a shipping quote before or after placing your order.

The BD-ES15i electric pallet stacker is a practical and efficient solution for lifting and transporting palletized loads in warehouses, production facilities, logistics centers, retail locations, and other working environments. With a 1500 kg load capacity and a maximum lifting height of 3500 mm, it is suitable for handling pallets, loading vehicles, and working with warehouse racking systems.

Electric driving and lifting reduce the physical effort required from the operator and make everyday material handling faster and easier. The LiFePO4 battery and integrated charger provide convenient operation, while the robust mast construction ensures stability during lifting. The multifunction control handle provides convenient control of driving, lifting, and lowering, while the display shows important operating information such as battery status, working hours, driving speed, and fault codes.

Features:

1500 kg load capacity for lifting and transporting palletized loads
Electric driving and electric lifting for easier and faster daily operation
Maximum lifting height of 3500 mm for warehouse racks and elevated loads
LiFePO4 battery with long service life and low maintenance requirements
Integrated charger for convenient charging from a 230 V power supply
Robust mast construction with C-shaped steel profiles for improved stability
Ergonomic multifunction control handle for driving, lifting, and lowering
Display showing battery status, working hours, driving speed, and fault codes
Slow driving mode for precise maneuvering in confined areas
Emergency stop switch for quick shutdown in unexpected situations
Key switch to restrict access to authorized operators
Protective mast guard helps protect the operator during operation
Regenerative braking for controlled and safe stopping
Polyurethane wheels designed for smooth movement on hard warehouse floors
Manual emergency mode allows operation when electric controls cannot be used

Technical specifications:

Rated load capacity: 1500 kg
Load center: 500 mm
Maximum lifting height: 3500 mm
Minimum fork height: 85 mm
Fork dimensions: 1150 × 160 × 65 mm
Overall fork width: 560 mm
Overall width: 800 mm
Overall length: 1735 mm
Overall height with forks lowered: 2240 mm
Overall height with forks fully raised: 3860 mm
Travel motor power: 0.75 kW
Lifting motor power: 2.2 kW
Battery voltage: 48 V
Battery capacity: 30 Ah
Battery type: LiFePO4
Travel speed with load: up to 4 km/h
Travel speed without load: up to 5 km/h
Lifting speed with load: 100 mm/s
Lifting speed without load: 200 mm/s
Lowering speed with load: 120 mm/s
Lowering speed without load: 100 mm/s
Gradeability with load: 5%
Gradeability without load: 8%
Turning radius: 1458 mm
Wheel material: polyurethane
Brake type: regenerative
Weight: 558 kg

The BD-ES15i electric pallet stacker is a reliable choice for businesses looking to improve daily material handling while reducing operator effort. Its 1500 kg capacity, 3500 mm lifting height, electric drive and lift system, LiFePO4 battery, and integrated safety features make it well suited for warehouses, logistics operations, production facilities, and other demanding working environments.
