El MaxiEV ITS100 es la herramienta definitiva para los técnicos que trabajan con sistemas de alta tensión en vehículos eléctricos. Sus completas funciones de comprobación, junto con la visualización de datos y el cumplimiento de las normas de seguridad internacionales, lo convierten en un complemento indispensable para cualquier kit de herramientas de mantenimiento de vehículos eléctricos.
Sí, ofrecemos envío internacional exprés rápido y gratuito para todos los productos disponibles en Balticdiag.com. Realizamos entregas a todo el mundo — incluyendo USA, Europa, América del Norte, América del Sur, Asia, África y Australia — utilizando servicios de mensajería confiables como DHL, UPS y FedEx. Cada pedido se envía con entrega exprés directamente a tu puerta, garantizando una llegada rápida y segura. Los costos de envío están incluidos en el precio del producto, y proporcionamos información de seguimiento completa para que puedas monitorear tu paquete desde el despacho hasta la entrega.
Aceptamos una amplia variedad de métodos de pago seguros internacionales y locales, incluyendo:
Safety Standards | Comply with IEC/EN 61010-1 1000V CAT Ⅲ, 600V CAT Ⅳ measurement standards |
Voltage Measurement | 1000Vdc voltage; 750Vac voltage (true valid value) |
Overload Protection | When performing voltage measurement, if the input terminals are V and COM, the max overload protect voltage is 1200V; if the input terminals are Hi and Lo, the overload protect voltage is 600V; In other test modes, the overload protect voltage is 250V (valid value) |
Tester Battery | A total of six 1.5V AA alkaline batteries; It supports completing at least 1000 insulation tests (standard test with conditions of 1000V, 1MΩ, and duty cycle of 5 seconds power on and 25 seconds power off) |
Insulation Measurement Range | 0.01MΩ~10.00GΩ |
Insulation Test Voltage | 50V, 100V, 250V, 500V, 1000V |
Insulation Output Voltage Accuracy | +20%, -0% |
Insulation Short Circuit Test Current | 1.8mA nominal value |
Insulation Auto-Discharge Time | When capacitance (C)=1μF or less, the discharge time < 1 second |
Insulation Live Circuit Detection | Before test initialization, if the terminal voltage > 20V, the alarm will occur and the test will be prohibited |
Insulation Max Capacitive Load | Operable with up to 1μF load |
Storage Temperature | -20°C~60°C |
Operating Temperature | 0°C~40°C |
Storage Altitude | 12000m |
Operating Altitude | 2000m 1000V CAT Ⅲ; 3000m 1000V Ⅱ |
Temperature Coefficient | Per (°C)X0.05X(specified accuracy) for temperature < 18°C or temperature > 28° |
Relative Humidity | 40%~75% (40%~60% when insulation test resistance > 1GΩ) |
Dimension (mm) | 194(L)*150(W)*72(H) |
Weight (g) | 950g |
Safety Standards | Comply with IEC/EN 61010-1 1000V CAT Ⅲ, 600V CAT Ⅳ measurement standards |
Voltage Measurement | 1000Vdc voltage; 750Vac voltage (true valid value) |
Overload Protection | When performing voltage measurement, if the input terminals are V and COM, the max overload protect voltage is 1200V; if the input terminals are Hi and Lo, the overload protect voltage is 600V; In other test modes, the overload protect voltage is 250V (valid value) |
Tester Battery | A total of six 1.5V AA alkaline batteries; It supports completing at least 1000 insulation tests (standard test with conditions of 1000V, 1MΩ, and duty cycle of 5 seconds power on and 25 seconds power off) |
Insulation Measurement Range | 0.01MΩ~10.00GΩ |
Insulation Test Voltage | 50V, 100V, 250V, 500V, 1000V |
Insulation Output Voltage Accuracy | +20%, -0% |
Insulation Short Circuit Test Current | 1.8mA nominal value |
Insulation Auto-Discharge Time | When capacitance (C)=1μF or less, the discharge time < 1 second |
Insulation Live Circuit Detection | Before test initialization, if the terminal voltage > 20V, the alarm will occur and the test will be prohibited |
Insulation Max Capacitive Load | Operable with up to 1μF load |
Storage Temperature | -20°C~60°C |
Operating Temperature | 0°C~40°C |
Storage Altitude | 12000m |
Operating Altitude | 2000m 1000V CAT Ⅲ; 3000m 1000V Ⅱ |
Temperature Coefficient | Per (°C)X0.05X(specified accuracy) for temperature < 18°C or temperature > 28° |
Relative Humidity | 40%~75% (40%~60% when insulation test resistance > 1GΩ) |
Dimension (mm) | 194(L)*150(W)*72(H) |
Weight (g) | 950g |
